Constellation®    ES.3
Capacity-Optimized Enterprise Hard Drive for Bulk-Data Applications
• Highest-capacity large form factor enterprise drive—up to 4TB—for demanding data growth1
• Sixth-generation drive technology with SAS and SATA interfaces for 24x7 reliability
• Enhanced error correction, super parity and end-to-end SAS-based data integrity for accurate data storage
• Best-in-class rotational vibration tolerance ensures consistent performance.
• Improved power and cooling efficiencies with low power consumption and on-demand PowerChoiceTM technology based on T10/T13 power management standards
• Multi-drive firmware maximized for enterprise RAID system availability
• Robust performance with dual processors, ramp load technology, top-cover- attached motor and humidity sensor for optimum performance in all chassis
• Self-Encrypting Drive (AES-256) with FIPS 140-2 validation and Seagate Instant Secure Erase cuts IT drive retirement costs while securely protecting data at rest.2,3

Best-Fit Applications
• High-capacity RAID storage
• Mainstream enterprise external storage arrays (SAN, NAS, DAS)
• Cloud bulk data storage
• Enterprise backup and restore—D2D, virtual tape
• Centralized surveillance




Performance Specifications
• Model Number ST1000NM0023
• Rotational Speed 7,200 RPM (nominal)
• Buffer Size 128MB
• Average Latency 4.16ms

  Physical Specifications
• Capacity 1TB
• Interface SAS 6Gb/s

Physical Dimensions
English
• Height .1028 Inches max
• Depth 5.878 inches max
• Width 4.010 inches
• Weight 1.334 Pounds
Metric
• Height 26.1 mm max
• Depth 147.0 mm max
• Width 101.85 mm
• Weight 605g
